Home /Products/High Pressure Mud Pump/200Kw Electric Motor High Pressure Mud Pump Cement Grouting Drilling
200Kw Electric Motor High Pressure Mud Pump Cement Grouting Drilling
1 set
MOQ
Negotiation
Price
200Kw Electric Motor High Pressure Mud Pump Cement Grouting Drilling
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: XiTan Equipment
Certification: CE;
Model Number: As customized
High Light:

200Kw High Pressure Mud Pump

,

Grouting Drilling High Pressure Mud Pump

,

200Kw drilling mud pump
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 7-120 days
Payment Terms: T/T
Supply Ability: 200 set/year
Specifications
Structure: Compact
Motor Power: 200 Kw
Application: Ground Improvement Construction
Performance: High Pressure, Variable Frequency
Inlet Diameter: 60 Mm
Outlet Diameter: 32 Mm
Package: Nude, Woody Box, As Customized
Condition: New
Product Description

200Kw Electric Motor High-Pressure Mud Pump Cement Grouting Drilling



This grouting pump is a universal high-pressure grouting pump and is used for grouting in soil, earth foundation stabilization, waterproofing, tunnel lining, underwater foundations, bridge decks, deep well casing, and slope line grouting, etc.



Technical Parameters(The below as reference)



Model

 XTB---60
Plunger diameter (mm) 85
Plunger stroke (mm) 152.4
Maximum grouting flow (L/min) 150
Maximum pressure (MPa) 45
Motor power (Kw) 200
Inlet diameter (mm) 60
Outlet diameter (mm) 32
Weight (Kg) 7200
Dimensions (mm) 3726X2400X2100





200Kw Electric Motor High Pressure Mud Pump Cement Grouting Drilling 0





Tag:

160KW Cement Grouting Pump

High Pressure Cement Grouting Pump

Mine cement pressure grouting machine
