Flow Monitoring High Pressure Mud Pump Cement Fluid Injection
1 set
MOQ
negotiable
Price
Flow Monitoring High Pressure Mud Pump Cement Fluid Injection
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: XITAN
Certification: CE;
Model Number: ZJB/BP90(A)
High Light:

Flow Monitoring High Pressure Mud Pump

,

Fluid Injection High Pressure Mud Pump

,

Fluid Injection electric mud pump

Payment & Shipping Terms
Packaging Details: Nude in 20gp Container
Delivery Time: 30-90days
Supply Ability: 100set Per Year
Specifications
Structure: Compact
Motor Power: 90kw
Application: Ground Improvement Construction
Performance: High Pressure, Variable Frequency
Inlet Diameter: 50mm
Outlet Diameter: 25mm
Package: Nude,woody Box,As Customised
Condition: NEW
Product Description

Neat Cment Grouting Injection Pump High Pressure Frequency Control

Application

Cment Grouting Pump is frequency conversion high pressure grouting pump,which often works together with cement mixer. The idea choice of engineering grouting.

It is applied in highway, railway, mine, port, national defense and other fields of foundation reinforcement, building settlement treatment, foundation impermeable curtain, retaining cofferdam, slope anchorage, mine plugging, shaft wall and other engineering construction.



Main feature

1. Electric mortar pump.

2. High performance mortar pumpt for pumping, helping cement injecting for gound improvement..

3. Simple and robust.

4. Easy to use.



Parameter

Model Name ZJB/BP 55 ZJB/BP 55 A ZJB/BP 90 ZJB/BP 90A ZJB/BP 132 ZJB/BP 132(A) ZJB/BP 250
Plunger diameter 45mm 55mm 45mm 55mm 60mm 65mm 90mm
Plunger stroke 120mm 120mm 120mm 120mm 100mm 100mm 152.4mm
Maximum grouting flow

114

L/min

160

L/min

114

L/min

160

L/min

150

L/min

170

L/min

280

L/min

Maximum pressure 30 MPa 20 MPa 45MPa 30MPa 50MPa 50MPa 45MPa
Motor power 55 Kw 55 Kw 90 Kw 90 Kw 132 Kw 132 Kw 250 Kw
Inlet diameter 50 mm 50 mm 50 mm 50 mm 50mm 50mm 65mm
Outlet diameter 25 mm 25 mm 25 mm 25 mm 25 mm 25 mm 32 mm
Total weight 1450 Kg 1450 Kg 2200 Kg 2200 Kg 2900 Kg 2900 Kg 8000 Kg
Dimentions 2348X1056X826 mm 2348X1056X826 mm 2490X1196X915 mm 2490X1196X915 mm 2673X1546X1100 mm 2673X1546X1100 mm 3350X2500X1800 mm








Flow Monitoring High Pressure Mud Pump Cement Fluid Injection 0

Flow Monitoring High Pressure Mud Pump Cement Fluid Injection 1

Flow Monitoring High Pressure Mud Pump Cement Fluid Injection 2
