Eco-Friendly SPT Soil Sampling Rig Hydraulic Crawler Direct Push
ESD-70 environmental sampling drilling rig is a new type of soil sampling rig. It is a full hydraulic drilling rig specially used in the field of environmental protection. The drilling rig uses a single impact power head, which is easy to operate and cost-effective.
The device has the following functions:
1. Direct push type undisturbed soil sampling.
2. Direct push for underground sampling.
3. Injection to soil and Contaminant treatment for pollution control
1. Thrust effectively
2. Without water
3. Drilling with a sampling tube
4. Multifunction equipment: Sampling and pollution treatment
|Sampling Diameter||110mm(the depth of sampling will be reduced)|
|Power Head Impact Frequency||≥3,000 Hz|
|Impact Power Head|
|Impact Frequency||3120/3990/4800 Hz|
|Impact Power||14.5 KW|
|Rotary Power Head|
|Rotation Speed||92/46 rpm|
|Power||75 kw/2500 rpm|
|Engine Model||Dongfeng Cummins QSB3.9-C100-31|
|Size||Transmission 4000X1800X2900 mm|
|Working 4130X1900X3160 mm|
