50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand
1
MOQ
Negotiation
Price
50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: XiTan Equipment
Certification: CE; ISO9001:2015
Model Number: ZJB/PB
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 7-120 days
Payment Terms: T/T
Supply Ability: 200 set/year
Specifications
Product Name: High Pressure Pump
Motor Power : 55Kw-132Kw
Weight : 1450Kg-2900Kg
Dimension: 2348X1056X826 Mm-2673X1546X1100 Mm
Maximum Pressure: 30 MPa-50 MPa
Plunger Diameter: 45 Mm-60 Mm
Plunger Stroke: 100 Mm-120 Mm
Product Description

50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand





Application of 50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand:

50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand products are suitable for the construction of foundation reinforcement, building settlement management, foundation seepage curtain, retaining cofferdam, slope anchoring, mine plugging, shaft wall protection, etc. in the fields of highway, railroad, mine, port, and national defense.





50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand 0





Feature of 50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand:

1. Use of intelligent control technology, real-time display of instantaneous flow, pressure, and cumulative flow and printing.

2. The hydraulic end employs a plunger lubrication structure, the seal effectively increases service life, easy and rapid replacement of wearing parts, and a sturdy and anti-wear alloy valve seat, minimizing the frequency of stopping and replacing parts.

3. Use of frequency converter speed control eliminates the need for a mechanical gearbox, clutch, and other multi-fault transmission components, resulting in a smaller, more reliable unit with a compact structure, smooth start-up operation, and reduced energy consumption, and minimal impact on the power grid.

4. The electrical control circuit is simple and reliable, through the simple operation panel, it can realize "foolproof" operation and display the basic operating parameters; it can set and display various operating parameters of the equipment.

5. 50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand includes a full range of protective features and can guard against and regulate power loss, phase loss, over-voltage, under-voltage, and over-current, torque, and pump pressure, among other things.

6. The whole adopts a container-type protection system (optional), which is environmentally friendly, simple, and easy to transport.

7. 50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand can meet the technical requirements of single-pipe, double-pipe, and three-pipe rotary spray pile construction and other ultra-high pressure rotary spray construction methods.



50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand 1



Technical Data:

Model Name ZJB/BP 55 ZJB/BP 55A ZJB/BP 90 ZJB/BP 90A ZJB/BP 132
Plunger Diameter 45 mm 55 mm 45 mm 55 mm 60 mm
Plunger Stroke 120 mm 120 mm 120 mm 120 mm 100 mm
Maximum Grouting Flow

114

L/min

160

L/min

114

L/min

160

L/min

150

L/min

Maximum Pressure 30 MPa 20 MPa 50 MPa 30 MPa 50 MPa
Motor Power 55 kW 55 kW 90 kW 90 kW 132 kW
Inlet Diameter 50 mm 50 mm 50 mm 50 mm 50mm
Outlet Diameter 25 mm 25 mm 25 mm 25 mm 25 mm
Total Weight 1450 Kg 1450 Kg 2200 Kg 2200 Kg 2900 Kg
Dimensions 2348X1056X826 mm 2348X1056X826 mm 2490X1196X915 mm 2490X1196X915 mm 2673X1546X1100 mm


50 MPa High-Quality Mud Pump for Rotary Spray Construction in Thailand 2

RFQ:

1. Are you the manufacturer?

Ans: Yes, we are a factory with more than 60years of manufacturing experience.



2. What are your terms of payment?

Ans: 50% deposit prepaid by T/T, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.



3. How about your delivery time?

Ans: Except for the GY60/80 model anchor drilling rig which is not in stock, the common drilling rig has in stock, and could be delivered in one week after getting your full payment.

Customize drilling rig will take 15-45 days after receiving your advance payment. The specific delivery depends on the items and the quantity of your order.



4. What is the warranty of our machine?

Ans: Our main machine enjoys one year warranty. But unreasonable operation and wearing parts exclude.



5. Do you test all your goods before delivery?

Ans: Yes, we have 100% test before delivery. And we will attach our inspection report for every machine.



6. Do you have after-service?
Ans: Yes, we have a special after-sales service team that will supply you with professional guidance. And we provide videos for machine installation and operation.

If you need, we can send our engineers to your worksite and provide the training for your staff.
